CT140 PC Cooling Fans are Thermaltake’s new generation PWM fans designed to fit all PC usage scenarios. The CT Series Fans have a fan speed of 1500 RPM and are made with specially tuned fan blades that can push the air further. The new Cable-Integrated Daisy-Chain Design provides more flexibility in cable management.
| P/N | CL-F147-PL12BL-A | CL-F148-PL14BL-A |
| Fan Dimension | 120 x 120 x 25 mm | 140 x 140 x 25 mm |
| Started Voltage | 5 V | 5 V |
| Rated Current | 0.11 A (one fan) | 0.17 A (one fan) |
| Rated Voltage | 12 V | 12 V |
| Power Input | 1.32 W (one fan) | 2.04 W (one fan) |
| Fan Speed | PWM 500~2000 R.P.M | PWM 500~1500 R.P.M |
| Max. Air Pressure | 2.23 mm-H2O | 2.3 mm-H2O |
| Max Air Flow | 57.05 CFM | 77.37 CFM |
| NOISE LEVEL | 25.8 dB-A | 30.5 dB-A |
| Bearing Type | Hydraulic Bearing | Hydraulic Bearing |
| Life Expectation | 40,000 hrs,25℃ | 40,000 hrs,25℃ |
| Connector | 4 PIN PWM | 4 PIN PWM |
| Other | PWM Cable x 2 | PWM Cable x 2 |
