Ideal for tech-savvy users and businesses, it enhances network performance with high-speed wireless capabilities.
Its robust design ensures reliability, making it perfect for demanding audio and multimedia applications.
With a local supplier warranty of three years, users can trust in its durability and support.
Experience uninterrupted streaming and efficient remote control access with this advanced wireless solution.
Highlight Features
* Manage up to 7,168 clients and 224 settled APs or 448 wall plate APs simultaneously.
* L2/L3 roaming, ensuring good mobility and security.
* Multi-WAN, intelligent load balancing.
* Unified Cloud Management for Easy O&M.
Specification
Key Specs
* Number of manageable Aps
> 32 (default), 448 (max.)
> Note: The number of APs that can be managed by the AC is subject to the AP model. See the Ordering Information for details.
* Max. number of configurable APs: 2,048
* Maximum number of manageable STAs
> 7,168
> Note: The maximum number of STAs that can be managed by the AC is subject to the network environment. Contact technical support team for details.
* 802.11 forwarding capacity: 1.58 Gbps (subject to the wireless network environment)
* WLAN service
> Max. number of WLAN IDs: 2,048
> Max. number of associated STAs per WLAN: 7,168
* Number of VLANs: 4,094
* Port
> Two 1GE combo interfaces (SFP interface and 10/100/1000Base-T auto-negotiation electrical interface)
> 6 x 10/100/1000Base-T Ethernet ports with auto-negotiation. Port 1 can be used as an out-of-band management port.
> 1 x RJ45 console port
> 2 x USB ports
* Power supply
> 1 x 40 W built-in power module
> Power input: 100 V AC to 240 V AC, 50 Hz to 60 Hz, 1.5 A (max. RMS current)
> Power output: 12 V DC, 3.33 A
* Max. power consumption: 40 W
* Rack height: 1 RU
* Applicable software version: RGOS11.9(6)W1B1 or higher
* Network management platform
> Web-based management (Eweb)
> WIS-based management (RG-iData-WIS)
> RG-Cloud
Hardware Specs
* Dimensions (W x D x H): 440 mm x 200 mm x 43.6 mm (17.32 in. x 7.87 in. x 1.72 in.)
* Weight
> Main unit: 2.85 kg (6.28 lbs)
> Shipping: 3.79 kg (8.36 lbs)
* Status LED
> SYS: 1 x system status LED
> PWR: 1 x power status LED
> Speed: 8 x electrical interface rate LEDs
> Link/ACT: 8 x electrical interface data transmission LEDs
> 7F and 8F: 2 x multiplexed optical interface status LEDs
* Button
> 1 x Reset button
~ Press the button for shorter than 2 seconds. Then the device restarts.
~ Press the button for longer than 5 seconds. Then the device restores to factory settings.
> 1 x Power switch button
* Environment
> Storage temperature: –40°C to 70°C (–40°F to +158°F)
> Storage humidity: 5% to 95% RH (non-condensing)
> Storage altitude: 0 m to 3,000 m (0 ft. to 9,842.52 ft.)
> Operating temperature: 0°C to 45°C (32°F to 113°F)
> Operating humidity: 10% to 90% RH (non-condensing)
> Operating altitude: 0 m to 3,000 m (0 ft. to 9,842.52 ft.)
> Note: At an altitude between 3,000 m (9,842.52 ft.) and 5,000 m (16,404.20 ft.), every time the altitude increases by 220 m (721.78 ft.), the maximum temperature decreases by 1°C (1.8°F).
* Fan
> Fan speed adjustment
> Fan fault alarm
* Acoustic noise: < 78 dB
* Mean Time Between Failure (MTBF): 400,000 hours (44 years) at the operating temperature of 25°C (77°F)
